Bredel hose pumps (10-50)

Overview

Bredel hose pumps (10-50)

Bredel hose pumps have no valves or seals to leak, clog or replace and provide flow rates to 4623 GPH (17520 L/h) and pressures to 232 psi.

They can pump viscous and abrasive slurries, pastes and sludge, with up to 80 % solids in suspension.

Unlike other pump types, the highly abrasive nature of grit-filled sludge or lime slurry in the environmental market, does not affect peristaltic hose pump life.

Bredel hose pumps eliminate ancillary equipment such as dry run protection, seal water flush systems and in-line check valves. They are also reversible to flush lines.

Chemical Compatibility Guide

Features and benefits

  • Dry running and self-priming
  • Suction lift capability of up to 9.14 m
  • Abrasion resistant hoses can double pump uptime and save energy
  • No seals, ball-checks, diaphragms, glands, immersed rotors, stators or pistons to leak, clog, corrode or replace
  • Handles abrasive slurries, corrosive acids, gaseous liquids
  • No slippage, allowing true positive displacement for accurate and repeatable metering
  • No ancillary equipment, check valves, sealing water flush systems or run-dry protection required
  • Fully reversible to blow out suction and drain lines safely

Technical summary

Max. flow rate continuous10512 L/h
Max. flow rate continuous2774 USGPH
Volume per revolution0.022 - 2.92 L
Max. continuous operating speed60 - 100 rpm
Max. operating pressure16 bar
Max. operating pressure232 psi
Operating temperature range-20 - 45 °C
Operating temperature range-4 - 113 °F
Min. starting torque47 - 620 N m
Min. starting torque416 - 5,487 in/lbs
Weight30 - 325 kg
Hose materialBioprene, CSM, EPDM, F-NBR, NBR, NBR for food, NR, NR Endurance

Technical Summary table lists features available within the range. See ‘Technical specifications’ tab for model specific information.

Performance

Performance

Bredel 10, Bredel 15 and Bredel 20

Bredel 25 and Bredel 32

Bredel 40 and Bredel 50

Specifications

Technical specifications

Bredel 10Bredel 15Bredel 20Bredel 25Bredel 32Bredel 40Bredel 50
Max. flow rate continuous105 L/h375 L/h600 L/h1800 L/h3200 L/h5985 L/h10512 L/h
Max. flow rate continuous28 usgph99 usgph158 usgph475 usgph844 usgph1579 usgph2774 usgph
Max. flow rate intermittent160 L/h525 L/h820 L/h2740 L/h5250 L/h9576 L/h17520 L/h
Max. flow rate intermittent 42 usgph139 usgph216 usgph723 usgph1385 usgph2527 usgph4623 usgph
Volume per revolution0.022 L0.083 L0.152 L0.3 L0.625 L1.33 L2.92 L
Volume per revolution0.0058 usg0.0219 usg0.0402 usg0.079 usg0.165 usg0.35 usg0.77 usg
Max. continuous operating speed80 rpm75 rpm65 rpm100 rpm85 rpm75 rpm60 rpm
Max. intermittent operating speed120 rpm105 rpm90 rpm155 rpm140 rpm120 rpm100 rpm
Max. operating pressure12 bar12 bar10 bar16 bar16 bar16 bar16 bar
Max. operating pressure174 psi174 psi145 psi232 psi232 psi232 psi232 psi
Suction pressure0.05 bar abs0.05 bar abs0.05 bar abs0.05 bar abs0.05 bar abs0.05 bar abs
Suction pressure0.73 psi abs0.73 psi abs0.73 psi abs0.73 psi abs0.73 psi abs0.73 psi abs
Max. inlet pressure2 bar abs2 bar abs2 bar abs3.5 bar abs3 bar abs2.5 bar abs2.5 bar abs
Max. inlet pressure30 psia30 psia30 psia51 psia44 psia38 psia38 psia
Operating temperature range-20 - 45 °C-20 - 45 °C-20 - 45 °C-20 - 45 °C-20 - 45 °C-20 - 45 °C-20 - 45 °C
Operating temperature range-4 - 113 °F-4 - 113 °F-4 - 113 °F-4 - 113 °F-4 - 113 °F-4 - 113 °F-4 - 113 °F
Fluid temperature range-20 - 80 °C-20 - 80 °C-20 - 80 °C-20 - 80 °C-20 - 80 °C-20 - 80 °C-20 - 80 °C
Fluid temperature range-4 - 176 °F-4 - 176 °F-4 - 176 °F-4 - 176 °F-4 - 176 °F-4 - 176 °F-4 - 176 °F
Min. starting torque47 N m60 N m85 N m115 N m210 N m320 N m620 N m
Min. starting torque416 in/lbs531 in/lbs752 in/lbs1018 in/lbs1859 in/lbs2832 in/lbs5487 in/lbs
Weight30 kg45 kg45 kg90 kg130 kg180 kg325 kg
Weight66 lbs99 lbs99 lbs198 lbs287 lbs397 lbs717 lbs
Hose lubricant required0.25 L0.5 L0.5 L2 L3.5 L5 L10 L
Hose lubricant required0.07 usg0.1 usg0.1 usg0.53 usg0.92 usg1.32 usg2.64 usg
Port configurationsDown, Left, Right, Up Down, Left, Right, Up Down, Left, Right, Up Down, Left, Right, Up Down, Left, Right, Up Down, Left, Right, Up Down, Left, Right, Up
Compatible hose materialsCSM, EPDM, F-NBR, NBR, NBR for food, NR, NR Endurance CSM, EPDM, F-NBR, NBR, NBR for food, NR, NR Endurance CSM, EPDM, F-NBR, NBR, NBR for food, NR, NR Endurance CSM, EPDM, F-NBR, NBR, NBR for food, NR, NR Endurance CSM, EPDM, F-NBR, NBR, NBR for food, NR, NR Endurance CSM, EPDM, F-NBR, NBR, NBR for food, NR, NR Endurance CSM, EPDM, F-NBR, NBR, NBR for food, NR, NR Endurance
Flange assembly typeANSI, DIN ANSI, DIN ANSI, DIN ANSI, DIN, JIS ANSI, DIN, JIS ANSI, DIN, JIS ANSI, DIN, JIS

Bredel 10, Bredel 15 and Bredel 20 - Dimensions

Type A A1 B C D ØE F G H H1 H2max J K Lmax L1 L2max M N O ØP
Bredel 10 (mm) 337 311 171 62 116 16 235 265 225 127 254 78 51 501 46 378 150 65 25 12
Bredel 10 (inches) 13.3 12.2 6.7 2.44 4.6 16mm 9.3 10.4 8.9 5.0 10.0 3.1 2 19.7 1.8 14.9 5.9 2.6 1.0 12mm
Bredel 15 (mm) 427 431 230 63 195 20 285 315 304 167 294 82 61 505 46 378 150 75 25 12
Bredel 15 (inches) 16.8 17.0 9.1 2.5 7.7 20mm 11.2 12.4 12.0 6.6 11.6 3.2 2.4 19.9 1.8 14.9 5.9 3.0 1.0 12mm
Bredel 20 (mm) 427 431 230 63 195 20/25.5* 285 315 304 167 294 82 61 505 46 378 150 75 25 12
Bredel 20 (inches) 16.8 17.0 9.1 2.5 7.7 20mm/25.5mm* 11.2 12.4 12.0 6.6 11.6 3.2 2.4 19.9 1.8 14.9 5.9 3.0 1.0 12mm
Connector sizes MNPT EN DIN JIS
Bredel 10 0.5" 10mm 10mm
Bredel 15 0.75" 20mm 20mm
Bredel 20 0.75" 20mm 20mm

Bredel 25 and Bredel 32 - Dimensions

Type A B C D E F G H H1 H2max J K Lmax L1 L2max M N O ØP ØQ R
Bredel 25 (mm) 521 304 2.5 264 98 279 315 460 222 359 66 97 592 58 468 305 120 15 12 14 85
Bredel 25 (inches) 20.5 12 0.09 10.4 3.9 11 12.4 18.1 8.7 14.1 2.6 3.8 23.3 2.3 18.4 12 4.7 0.6 0.47 0.6 3.3
Bredel 32 (mm) 631 375 2.5 330 105 324 360 538 260 402 72 93 684 68 544 370 120 20 12 18 100
Bredel 32 (inches) 24.8 14.8 0.09 13 4.1 12.8 14.2 21.2 10.2 15.8 2.8 3.7 26.9 2.7 21.4 14.6 4.7 0.79 0.47 0.71 3.94
Connector sizes ANSI 150# EN DIN JIS
Bredel 25 1" 25mm 25mm
Bredel 32 1.25"/1.5" 32mm 32mm

Bredel 40 and Bredel 50 - Dimensions

Type A B C D E F G H H1 J K Lmax L1 L2max M N O ØP ØQ R
Bredel 40 (mm) 705 412 2.5 430 110 490 540 643 325 73 84 906 91 301 300 120 30 18 18 110
Bredel 40 (inches) 27.8 16.2 0.09 16.9 4.3 19.3 21.3 25.3 12.8 2.9 3.3 35.7 3.6 11.9 11.8 4.7 1.2 0.71 0.71 4.3
Bredel 50 (mm) 838 475 3 554 143 620 680 811 420 84 95 975 112 339 380 155 40 18 18 125
Bredel 50 (inches) 32.9 18.7 0.12 21.8 5.6 24.4 26.8 31.9 16.5 3.3 3.7 38.4 4.4 13.3 15 6.1 1.6 0.71 0.71 4.9
Connector sizes ANSI 150# EN DIN JIS
Bredel 40 1.5" 40mm 40mm
Bredel 50 2" 50mm 50mm

Materials of construction

Hose materialBioprene, CSM, EPDM, F-NBR, NBR, NBR for food, NR, NR Endurance
HousingCast iron
Rotor assemblyCast iron
Cover assemblyCast iron, Mild steel
Brackets and fastenersGalvanized steel, Stainless steel 316
Support frameGalvanized steel, Stainless steel 316
Hose clampsGalvanized steel, Stainless steel 316
Coupling brushAlloy steel
SealsEPDM, Neoprene, Nitrile

Recommended Products

  1. Buna N (NBR) hose

    Buna N (NBR) hose

    Buna N (NBR) hose elements. Resistant to oils, greases, alkalis and detergents.
